AGV Transfer Carts

Capacity:5-300t
Gage of rail:762-1435mm
L*W:3000*1500-12800*2800MM
Height:520-1350mm
Motor power:2.2-15kw
Travelling speed:15-30m/min

Product description

Industrial transfer carts have become a preferred choice for in-plant or short-distance inter-facility transportation, thanks to their convenience, cost-effectiveness, practicality, and ready availability. Heavy-duty flat carts are mainly used in applications such as movable pouring ladle transfer, brick factories, refractory plants, ceramic factories, and electric sanitation removal vehicles. Additionally, smaller transfer carts (such as pallet transfer carts) are also widely applied in milling plants, concentrating mills, foundries, chemical plants, furnace charge handling, farms, and various other industrial settings.

Explosion-proof electric transfer carts delivery to US

Features and Advantages:

It features high explosion-proof and high-temperature resistant performance. The electric transfer cart imposes no strict requirements on track construction, enabling safe, flexible, and user-friendly operation. Additionally, its traveling speed can be adjusted according to practical needs.

ModelKPX-2tKPX-20tKPX-50tKPX-100tKPX-150t
Rated Load(t)22050100150
TableSize(mm)Length(L)200040005500650010000
Width(W)15002000250028003000
Heigth(H)4505506508501200
Wheel Base(mm)12002800420049007000
Rail Inner Gauge(mm)12001435143520002000
Wheel Diameter(mm)270350500600600
Wheel Quantity44448
Ground Clearance(mm)5050507575
Running Speed(mm)2520202018
Motor Power(kw)0.82.55.51115
Max Wheel Load(KN)14.477.7174343.8265.2
Reference Weight(t)2.35.57.613.926
Recommended Rail ModelP15P24P43QU100QU100
